| Brand Name : | HM |
| Price : | USD 80000-150000 |
| Payment Terms : | D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 200 sets one year |
| Delivery Time : | 10days |
Wood finish machine for whole set steel door decoration Application
This kind of vacuum transfer printing machine (wood effect decoration machine) is multi-function decoration machine for whole set steel door,door
frame, steel sheet and embossed steel sheet and strange shape aluminum profile,which is high efficiency (double alternative working tables). It
takes 5~8mins to finish whole set steel door wood effect
decoration.
It is widely used in security door,steel wood door,steel door,fire door,aluminum door,stainless door,large iron gate, whole set metal door,single leaf
metal door, double sides steel door,molded steel door,metal door body, steel door frame,and strange shape aluminum profiles,ladders,window
profile,kitchen applications,glass product,ceramic tiles...
Specifications of wood finish machine for whole set steel door | |
Items | Standard type with one working bed |
Day capacity | 240pcs steel sheets,50 sets mold doors |
Max Power | 12KW |
Machine overall size | L4500mm*W3500mm*H1650mm or customized |
Working table size(L*W) | 3500mm*1500m or customized |
Land required (L*W*H) | Customized |
Labor required (persons) | 1~2 |
Vacuuming system | 2 sets hydraulic |
Silicone membrane working table | 2 sets |
Waste exhausting and security system | 2 sets |
Heat preservation device | 2 sets |
Heating power | 1.2KW |
Vacuum pump power | 1.5KW |
Heating time | 3~5min |
Transfer printing temperature | 230~265℃ |
Machine weight | 1300~2200KG |
3.1.Perfect decoration effect: Wood effect decoration is good,
clear patterns,strong adhesion,without decoration leakage on deep
slot,corner turns
3.2.Low cost and high efficiency :Compared to original manual transfer printing method,no need glue,this new type transfer printing machine has
two working tables (alternative working),1~2 workers enough to finish the whole working process. It takes 5~8 mins to finish wood effect
decoration process,open the working table,the transfer paper will
drop off automatically,no any additional working process.
3.3.Durable:
1)The vacuum suction use special fluorine silicone material,good
adsorption,heat resistance and long life time
2) Electric control system adopts domestic and foreign well-known brands which is safe and reliable.Ensure the transfer printing machine running
safely and effectively,reduce frequency and cost of maintenance.
3.4. Easy operation: It is very easy to operate this machine,no need more technical training.
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
Guarantee and after-sale service
The guarantee period of machinery is 12 months after shipping. The
buyer should follow the operation instruction and maintenance
instruction provided by the seller. Within the guarantee time, the
buyer should be responsible for quality problem of the equipment
except for man-made damage or problem caused by wrong operation.
After guarantee period, the seller will provide necessary support
on the customer’s demand and charge reasonablely based on material
cost.
|
|
